TOSHON TIG/ARC 315BP AC/DC 3PHASE MOSFET
TOSHON
WELDING MACHINE
100 In Stock
TOSHON TIG/ARC 315BP AC/DC 3PHASE MOSFET
Product Specification:
| Model Name/Number | TIG / ARC 315 BP AC / DC 3 Phase - Mosfet |
| Voltage | AC230V +/- 15% |
| Rated Input Current | 13.6 A |
| Output Current Range | 5-315 A |
| Brand | Toshon |
| Frequency | 50/60 Hz |
| Power Factor | 0.93 |
| Efficiency | 85 % |
| Duty Cycle | 85 % |
| Dimension | 22.5 x 14.5 x 21 Inch |
| No Load Loss | 40 W |
| No Load Voltage | 60 V |
| Input Power Capacity | 8.9 KVA |
| Housing Protection Grade | IP21 |
| Net Weight | 34 kg |
Product Description:
Features:
- Excellent Square Wave Power Source; Capable of running through the zero current position; Featured with a very stable arc but without high frequency
- Good Arc Stiffness, Heat-Concentration and Easy to Operate With the Wire Feeding
- Strong capability to clean up the oxide on the surface, the width of cleaning pulse can be continuous adjusted, capable of generating a bright, smooth and nice seam
- Equipped with the output connection for the foot control pedal, convenient for the welding operation
- Built-in the protection circuits of over-current, over-heat, over-voltage, less-voltages and even alarming function as well, very safe and reliable.
